CFITSIO Fuzzing: Memory Corruptions and a Codex-Assisted Pipeline
20 Apr 2026 - Posted by Adrian DenkiewiczHave you ever wondered how those amazing space photos are taken? Are they exclusive to the big telescopes floating in space or can you take one from your backyard? What does it take to extract hydrogen colors out of a seemingly black sky?
Those are great questions, but you won’t learn it from here.
Instead, I’ll show how I set up and performed fuzzing of the CFITSIO library which is how those space photos are usually processed. I’ll show how the bugs were triaged at scale, and how Codex was used to unblock the fuzzing and to develop the initial security fixes.
Note: the work described in this blogpost used the GPT-5-Codex, which was the latest model I had access to at the time.
FITS Format
The Flexible Image Transport System (FITS) is a data standard created in the late 1970s by NASA, ESA, and the broader astronomy community. It started as a way to exchange telescope imagery across heterogeneous systems, but it evolved into a container for complex datasets: primary images, binary/ASCII tables, compressed tiles, world coordinate metadata, and instrument-specific headers. Today, most observatories, satellite missions, and even backyard observatories output FITS directly, so the ecosystem of tools is rich. Under the hood, FITS is far more than a simple image file - it routinely carries gigabyte-scale mosaics, time-series cubes, and calibration tables. The current FITS standard lives in a dense spec and most of it addresses astronomy beyond typical astrophotography - radio, infrared, X-ray, time-series, and polarization data with all their metadata are first-class in the spec, while backyard imaging uses only a small slice. Once telescopes and CCD cameras got cheap enough for hobbyists, the community needed tooling that already worked, so adopting FITS was the obvious shortcut. The format was battle-tested and carried all the metadata serious imaging needed. Ultimately, hobbyists inherited a rather complex data format that rarely changes because backward compatibility with old files is still mandatory.
There are several different libraries that claim to support the FITS format. Usually though, that only means some subset of the spec. CFITSIO is the most complete implementation and the library is used by numerous great pieces of astronomy software, therefore it piqued my interest.
For my fuzzing corpus, I’ve used some of my own astrophotos along with several public samples. I’m sure the coverage could be vastly improved with the right set of specialized data.
First Round: Generic Fuzzing
Initially, I began fuzzing using the standard AFL++ workflow. Harness code, testing corpus, some optimizations, with several sessions running over two weeks. This resulted in a security advisory consisting of six different bugs.
It was a quick experiment to see how fruitful the fuzzing could be and how the communication with the NASA team works. Fortunately, the cooperation was great and issues were quickly addressed by the HEASARC team.
Second Round: EFS
Having the setup ready to go, I decided to give it another shot. Testing was performed against cfitsio-4.6.3 which included fixes to previously reported issues. This time, I focused exclusively on the Extended Filename Syntax (EFS) which got my interest earlier. It’s a set of filters, enclosed in square brackets, that can be used to modify the raw file in various ways before it is opened and read by the application. Although EFS looks like a filename parser on the surface, it’s effectively a mini-language: image slicing, histogram generation, filters, pixel expressions, region filtering, arithmetic expressions, and the entire parser stack behind them.
An example FITS filename can look like this: myfile.fits[EVENTS][col Rad = sqrt(X**2 + Y**2)]
This opens a FITS file, selects the EVENTS extension, and creates a new column computed from existing data. The library does all of that before the application sees a single byte. The filename alone triggers extension lookup, column arithmetic, and a temporary file copy. Each bracket pair activates a different parser subsystem inside CFITSIO.
This represents a very interesting attack surface and it’s exposed in more places than people might think. Many applications accept filenames directly from external callers without realizing that CFITSIO will interpret them through EFS if only the fits_open_file or similar method is called (a non-EFS alternative: fits_open_diskfile also exists). If those filenames come from untrusted input, the attack path is open.
This time, as I didn’t have too much dedicated time, I’ve strongly relied on help from the GPT/Codex. First, it generated the harness code and some helpful cleanup utilities. The harness itself is minimal: it reads a filename string from a file, passes it to fits_open_file in read-only mode, then exits. That’s enough to exercise the entire EFS parsing and evaluation pipeline (or most of it, as I learned later), without needing complex application logic.
Early fuzzing cycles not only resulted in a lot of crashes, but also unexpected files created all over the filesystem and with the input FITS file being repeatedly destroyed. This wasn’t hard to fix though. I then asked GPT to look at the spec and the code and create a dictionary tailored to EFS tokens.
Within hours I had some clean crashes. This was nothing surprising given how much logic CFITSIO runs before it ever opens a file. Some days later, I ran AFLtriage and observed that there are just three different bugs responsible for all crashes I was seeing. The fuzzer couldn’t move on any further and coverage also barely moved. Even relatively simple code paths were unreachable with random mutations constantly hitting the same shallow error paths.
To keep going, I had to automate more of the workflow. That’s when I brought in Codex again.
Workflow Improvements
I loaded the CFITSIO/harness sources into Codex and fed it the crash reports along with the input files. Within seconds, it identified the root cause of each issue. It also gave me correct functions, correct offsets, correct control flow, and assumptions that failed. It pointed to actual logic errors, such as operator-precedence mistakes, unchecked token lengths or unbounded concatenations. I was surprised how fast and accurate the analysis was.
The next step involved asking for the patch and applying it. This completely unblocked my fuzzing. I restarted the process using the old output directory with a new harness build and… left it running.
Two weeks later, I had to stop the fuzzing and started investigating. AFLtriage again was very useful to quickly identify unique crashes. Learning from past experience, I went with Codex as my assistant again. After a few manual experiments I automated the following pipeline:
- providing crash context and source code to Codex,
- applying the proposed patch with a proper commit message,
- rebuilding CFITSIO (with AFL++ and ASAN instrumentation included),
- linking my fits-opener harness,
- re-running the crashing input under ASAN,
- confirming the fix and absence of regressions (including memory leaks).
Some fixes required multiple iterations. A patch that fixed an overflow might introduce a memory leak or leave an error path inconsistent. The automated loop caught those kinds of bugs. With just one verification test, it’s extremely likely that some functional issues were introduced. On the other hand, I skimmed the patches and they looked really solid, so… maybe not?
I repeated this process from scratch several times and ended up with 16 unique vulnerabilities, each pretty well understood, reproduced, and isolated.
Most of the bugs were from the old-school C string handling meets attacker-controlled input category. Some mismatched size checks on strncat, some stale realloc pointers, and some integer overflows in array math. This led to overflows on the stack and heap.
I did not attempt to weaponize any of the findings. CFITSIO might be used on so many platforms that some of them definitely miss even the most basic security mitigations. On the other hand, a quick inspection of stack overflows led me to believe that function frames are enormous and reaching control over RIP, or any function pointer, might be really challenging.
Example finding
Here is a brief overview of one of the findings (CFITSIO-EFS-01). It’s a typical syntax trap that most people will overlook but fuzzing should easily find.
In the Extended Filename Syntax, row filter expressions are encoded inside square brackets, like file.fits[2:f[R:f...]. The function ffifile2 accumulates them into a stack buffer called rowfilterx. Before each concatenation, it checks whether the new chunk would overflow the buffer:
if (strlen(rowfilterx) + (ptr2-ptr1 + (*rowfilterx)?4:0) > FLEN_FILENAME - 1) {
free(infile);
return(*status = URL_PARSE_ERROR);
}
Looks reasonable at a glance. There’s even a comment above it: “add extra 4 characters if we have pre-existing expression”. The intent is clear: if rowfilterx already holds something, the code wraps the new piece with ((...)), so it needs 4 extra bytes.
The problem is C operator precedence. The ternary ?: has lower precedence than +, so the expression actually evaluates as:
(strlen(rowfilterx) + (ptr2-ptr1 + (*rowfilterx)) ? 4 : 0) > FLEN_FILENAME - 1
That whole left side of ? is always non-zero (it’s a positive length sum), so the result is always 4 > FLEN_FILENAME - 1, which is always false. The if statement is never entered. Crafted filenames bypass it and strncat writes past rowfilterx, corrupting adjacent stack data.
The fix is just parentheses:
if (strlen(rowfilterx) + (ptr2 - ptr1 - 1) + ((*rowfilterx) ? 4 : 0) > FLEN_FILENAME - 1) {
This is the kind of bug where the developer clearly knew what they were protecting against. Yet, they got busted. It’s also a perfect example of what makes the Codex-assisted debugging effective. I handed it the crashing input, the ASAN trace, and the source file. Given those, it pinpointed the precedence issue right away.
Advisory
On November 17, 2025, the complete package — advisory, patches, crash files, and reproduction steps - was sent to the HEASARC/NASA maintainers. All code patches were Codex-generated. Since I don’t have access to a sufficient representation of real-world FITS files, I couldn’t validate functional regressions myself outside of a couple of test cases.
Once the security fixes landed in the repository, the team confirmed that the patches were very useful and even in the cases where ultimate fixes differed from the provided patches, they were still helpful to illustrate the problem. Some of them were applied without any changes.
The full advisory can be found here.
Closing Thoughts
Combining AFL++ with automated static guidance and automated fix validation proved to be very effective on a complex, legacy-heavy codebase and saved me a ton of time. I’m also happy that the HEASARC/NASA maintainers found the patches useful.
For the time being, I do not intend to continue CFITSIO fuzzing. Sadly, I believe there are still numerous memory issues lurking in old codebases like this. I hope that emerging security-oriented LLMs will be especially useful for identifying and fixing issues in projects appearing to the community as less interesting than the next major browser or CMS.
The story is not over yet though. Besides the memory issues presented in this post, separate logical bugs in EFS were discovered and will be soon disclosed. Stay tuned!
In other news, I will be presenting more about NASA’s CFITSIO Extended Filename Syntax at BSidesLuxembourg 2026. See you there!
